Alstom 333.3

Built by Alstom

Top speed

120 km/h

75 mph

Power output

2,240 kW

3,004 hp

Weight

120 t

264,554 lb

Length

22.33 m

73 ft 3 in

Track gauge

1,668 mm

Iberian gauge

Years built

2002–2003

Overview of the Alstom 333.3

Discover the versatile 333.3 diesel locomotive, a powerhouse from Alstom's Prima family. Built between 2002 and 2003, this impressive locomotive boasts a robust design and a top speed of 120 km/h.

With a 1668 mm gauge and Co'Co' wheel arrangement, the 333.3 is engineered for demanding operations. It measures 22.33 meters in length and is designed for an axle load of 20 tonnes, making it a reliable choice for various railway operators in Spain and Portugal.

Powered by an EMD 16-645E3 engine, this locomotive delivers 2240 kW of power and generates an impressive tractive effort of 341 kN. Its versatility is highlighted by its use by renowned companies such as Renfe Operadora, Acciona Rail Services, and MEDWAY, underscoring its significance in rail transport.

Alstom 333.3 technical specifications

	Value	Imperial / US
Series	333
Family	Prima
Built by	Alstom · 2002–2003
Top speed	120 km/h75 mph	75 mph
Power output	2,240 kW3,004 hp	3,004 hp
Tractive effort	341 kN76,660 lbf	76,660 lbf
Prime mover	EMD 16-645E3
Track gauge	1,668 mmIberian gauge5 ft 5⅝ in	5 ft 5⅝ in
UIC axle arrangement	Co'Co'
Length	22.33 m73 ft 3 in	73 ft 3 in
Width	3.16 m10 ft 4 in	10 ft 4 in
Height	4.31 m14 ft 2 in	14 ft 2 in
Weight	120 t264,554 lb	264,554 lb
Axle load	20 t44,092 lb	44,092 lb

Source of the data: en.wikipedia.orgView this model on trainspo.com Spotted an error? Let us know

Operators of the Alstom 333.3

Railway companies that have operated the 333.3, with the class designation used by each of them.

Operator	Class	Country
MEDWAY - Operador Ferroviário e Logistico de Mercadorias	Medway 333.3	Portugal
Acciona Rail Services S.A.	ARS 333.3	Spain
Athos Rail	Athos Rail 333.3	Spain
Captrain España	CTES 333.3	Spain
Continental Rail	Continental Rail 333.3	Spain
Convensa: Grupo FCC	CV 315.3	Spain
GO Transport	GOTRA 333.3	Spain
Grupo COMSA / COMSA EMTE	COMSA 333.3	Spain
Low Cost Rail	LCR 333.3	Spain
Renfe Operadora	RENFE 333.3	Spain
Tracción Rail	Tracción Rail 333.3	Spain
Transitia Rail	Transitia Rail 333.3	Spain
Transportes Ferroviarios Especiales	Transfesa 333.3	Spain
