Alstom BB 16500

Built by Alsthom

Top speed

140 km/h

87 mph

Power output

2,580 kW

3,460 hp

Weight

80 t

176,370 lb

Length

14.4 m

47 ft 3 in

Track gauge

1,435 mm

Standard gauge

Years built

1958–1964

294 units

Overview of the Alstom BB 16500

Discover the BB 16500, an iconic electric locomotive that served the French National Railway Corporation (SNCF).

Built by Alsthom between 1958 and 1964, this robust machine is a testament to French railway engineering, known for its reliability and performance.

With a standard gauge of 1435 mm and a powerful output of 2580 kW, the BB 16500 was capable of reaching speeds of 140 km/h, making it an efficient workhorse for various services.

Measuring 14.4 meters in length and weighing 80 tons, this electric locomotive developed a tractive effort of 324 kN, showcasing its strength. Explore the history and specifications of this significant piece of railway heritage.

Alstom BB 16500 technical specifications

	Value	Imperial / US
Series	BB 8500
Built by	Alsthom · 1958–1964294 units
Top speed	140 km/h87 mph	87 mph
Power output	2,580 kW3,460 hp	3,460 hp
Tractive effort	324 kN72,838 lbf	72,838 lbf
Electric systems	25 kV AC 50 Hz
Track gauge	1,435 mmStandard gauge4 ft 8½ in	4 ft 8½ in
UIC axle arrangement	B'B'
Length	14.4 m47 ft 3 in	47 ft 3 in
Width	2.98 m9 ft 9 in	9 ft 9 in
Height	3.58 m11 ft 9 in	11 ft 9 in
Weight	80 t176,370 lb	176,370 lb
