ANF Z 8800

Built by CIMT, ANF, TCO

Top speed

140 km/h

87 mph

Power output

3,000 kW

4,023 hp

Weight

221 t

487,221 lb

Track gauge

1,435 mm

Standard gauge

Years built

1984–1988

Overview of the ANF Z 8800

Explore the Z 8800, a powerful electric multiple unit (EMU) series.

Designed for the French National Railway Corporation (SNCF), this model, also known as the Z 20500, was built between 1984 and 1988 by CIMT, ANF, and TCO.

With a top speed of 140 km/h and an impressive power output of 3000 kW, it is ideally suited for regional passenger transport.

The Z 8800 features a four-car formation and a standard gauge of 1435 mm.

These EMUs are a vital part of the French rail network, offering comfort and efficiency to travelers.

ANF Z 8800 technical specifications

	Value	Imperial / US
Series	Z 20500
Family	Z2
Built by	CIMT, ANF, TCO · 1984–1988
Top speed	140 km/h87 mph	87 mph
Power output	3,000 kW4,023 hp	4,023 hp
Tractive effort	310 kN69,691 lbf	69,691 lbf
Electric systems	25 kV AC 50 Hz 1.5 kV DC
Track gauge	1,435 mmStandard gauge4 ft 8½ in	4 ft 8½ in
Formation	4 cars
Car length	98.76 m324 ft 0 in	324 ft 0 in
Width	2.85 m9 ft 4 in	9 ft 4 in
Height	4.32 m14 ft 2 in	14 ft 2 in
Weight	221 t487,221 lb	487,221 lb
