BBC DB E 50

Built by Krupp, AEG, BBC, Henschel, Krauss-Maffei, SSW

Top speed

100 km/h

62 mph

Power output

4,500 kW

6,035 hp

Weight

128 t

282,191 lb

Length

19.49 m

63 ft 11 in

Track gauge

1,435 mm

Standard gauge

Years built

1957–1973

194 units

Overview of the BBC DB E 50

Discover the powerful DB E 50 electric locomotive, a significant workhorse from Deutsche Bahn AG.

Built between 1957 and 1973 by a consortium of renowned manufacturers including Krupp, AEG, BBC, Henschel, Krauss-Maffei, and SSW, this locomotive boasts a robust construction and a storied history in German railway operations.

With a top speed of 100 km/h and a formidable power output of 4500 kW, the DB E 50 is engineered for demanding tasks. Its impressive tractive effort of 438 kN ensures it can handle substantial loads with ease.

This electric locomotive features a standard gauge of 1435 mm and a Co'Co' wheel arrangement, indicative of its strong hauling capabilities. Its substantial weight of 128 tonnes and impressive dimensions contribute to its stability and performance on the tracks.

The DB E 50 operates on 15 kV AC 16.7 Hz electric systems, a testament to its specialized design. Explore the specifications of this classic locomotive and its lasting impact on rail transport in Germany.

BBC DB E 50 technical specifications

	Value	Imperial / US
Built by	Krupp, AEG, BBC, Henschel, Krauss-Maffei, SSW · 1957–1973194 units
Top speed	100 km/h62 mph	62 mph
Power output	4,500 kW6,035 hp	6,035 hp
Tractive effort	438 kN98,466 lbf	98,466 lbf
Electric systems	15 kV AC 16.7 Hz
Track gauge	1,435 mmStandard gauge4 ft 8½ in	4 ft 8½ in
UIC axle arrangement	Co'Co'
Length	19.49 m63 ft 11 in	63 ft 11 in
Width	3.13 m10 ft 3 in	10 ft 3 in
Height	3.95 m13 ft 0 in	13 ft 0 in
Weight	128 t282,191 lb	282,191 lb
