CRRC Datong HXD3 / SSJ3 / DJ3

Built by CRRC Beijing, CNR Dalian, CNR Datong, Toshiba

Top speed

120 km/h

75 mph

Power output

7,200 kW

9,655 hp

Weight

150 t

330,693 lb

Length

20.85 m

68 ft 5 in

Track gauge

1,435 mm

Standard gauge

Years built

2006–2011

1,040 units

Overview of the CRRC Datong HXD3 / SSJ3 / DJ3

Discover the powerful HXD3 / SSJ3 / DJ3 electric locomotive, a robust engine designed for heavy-duty railway operations in China.

This impressive locomotive, operated by China Railway Corporation, boasts a formidable power output of 7200 kW and a maximum tractive effort of 570 kN, making it ideal for hauling demanding freight and passenger services.

Built by renowned manufacturers like CRRC Beijing, CNR Dalian, CNR Datong, and Toshiba between 2006 and 2011, the HXD3 / SSJ3 / DJ3 features a Co'Co' wheel arrangement and operates on standard 1435 mm gauge track.

With a top speed of 120 km/h, a length of 20.85 meters, and a substantial weight of 150 tons, this electric locomotive is a cornerstone of modern Chinese rail transportation.

Its advanced electrical systems utilizing 25 kV AC 50 Hz ensure efficient and reliable performance across the network.

CRRC Datong HXD3 / SSJ3 / DJ3 technical specifications

	Value	Imperial / US
Built by	CRRC Beijing, CNR Dalian, CNR Datong, Toshiba · 2006–20111,040 units
Top speed	120 km/h75 mph	75 mph
Power output	7,200 kW9,655 hp	9,655 hp
Tractive effort	570 kN128,141 lbf	128,141 lbf
Electric systems	25 kV AC 50 Hz
Track gauge	1,435 mmStandard gauge4 ft 8½ in	4 ft 8½ in
UIC axle arrangement	Co'Co'
Length	20.85 m68 ft 5 in	68 ft 5 in
Width	3.1 m10 ft 2 in	10 ft 2 in
Height	4.1 m13 ft 5 in	13 ft 5 in
Weight	150 t330,693 lb	330,693 lb
