Kinki Sharyo Sound Transit 100

Built by Kinki Sharyo

Top speed

105 km/h

65 mph

Power output

280 kW

375 hp

Weight

46 t

101,413 lb

Length

28.34 m

93 ft 0 in

Track gauge

1,435 mm

Standard gauge

Years built

2006

62 units

Overview of the Kinki Sharyo Sound Transit 100

Explore the Sound Transit 100, a modern tram built by Kinki Sharyo in 2006.

This locomotive, also classified as SDRX 100, operates in the United States under Sound Transit. It features a train length of 28.34 meters and a width of 2.65 meters, optimized for a capacity of 74 seats.

With a top speed of 105 km/h, it is powered by a 1.5 kV DC electric system, delivering a robust 280 kW of power. The Sound Transit 100 stands out with its standard 1435 mm gauge, a height of 3.77 meters, and a weight of 46 tonnes.

Kinki Sharyo Sound Transit 100 technical specifications

	Value	Imperial / US
Built by	Kinki Sharyo · 200662 units
Top speed	105 km/h65 mph	65 mph
Power output	280 kW375 hp	375 hp
Electric systems	1.5 kV DC
Track gauge	1,435 mmStandard gauge4 ft 8½ in	4 ft 8½ in
Capacity	74 seats
Train length	28.34 m93 ft 0 in	93 ft 0 in
Width	2.65 m8 ft 8 in	8 ft 8 in
Height	3.77 m12 ft 4 in	12 ft 4 in
Weight	46 t101,413 lb	101,413 lb
