Voith Maxima 30CC

Built by Voith

Power output

2,750 kW

3,688 hp

Length

23.2 m

76 ft 1 in

Track gauge

1,435 mm

Standard gauge

Years built

2006

Axle arrangement

C'C'

Overview of the Voith Maxima 30CC

Discover the Maxima 30CC, a powerful diesel locomotive renowned for its robustness and versatility.

Built by Voith in 2006, this impressive locomotive operates on a 1435 mm gauge and boasts an impressive power output of 2750 kW.

With a tractive effort of 408 kN, the Maxima 30CC is ideally suited for heavy freight transport and various railway construction projects.

It is deployed in Germany by prominent companies such as Havelländische Eisenbahn AG, STRABAG SE, and Wiebe Gleisbau GmbH, highlighting its reliability and broad applicability.

The C'C' axle arrangement and a length of 23.2 meters make it a powerful and stable unit on the rails.

Voith Maxima 30CC technical specifications

	Value	Imperial / US
Series	Voith Maxima
Built by	Voith · 2006
Power output	2,750 kW3,688 hp	3,688 hp
Tractive effort	408 kN91,722 lbf	91,722 lbf
Track gauge	1,435 mmStandard gauge4 ft 8½ in	4 ft 8½ in
UIC axle arrangement	C'C'
Length	23.2 m76 ft 1 in	76 ft 1 in

Source of the data: en.wikipedia.orgView this model on trainspo.com Spotted an error? Let us know

Operators of the Voith Maxima 30CC

Railway companies that have operated the Maxima 30CC, with the class designation used by each of them.

Operator	Class	Country
Havelländische Eisenbahn AG	HVLE 236	Germany
Schiene Gütern Logistik	SGL V400	Germany
STRABAG SE	STRABAG 263	Germany
Voith Turbo Lokomotivtechnik	VTLT 263	Germany
Wiebe Gleisbau GmbH	Wiebe 263	Germany
