Comeng NSW 86

Built by Comeng

Top speed

130 km/h

81 mph

Power output

2,700 kW

3,621 hp

Weight

119 t

262,350 lb

Track gauge

1,435 mm

Standard gauge

Years built

1982–1985

50 units

Axle arrangement

Co'Co'

Overview of the Comeng NSW 86

Discover the powerful NSW 86 electric locomotive, a versatile workhorse designed for heavy freight and passenger duties in Australia.

Built by Comeng between 1982 and 1985, these robust locomotives feature a Co'Co' wheel arrangement and boast impressive specifications.

With a top speed of 130 km/h and a significant power output of 2700 kW, the NSW 86 is equipped for demanding railway operations.

Its substantial weight of 119 tonnes and a tractive effort of 222 kN ensure reliable performance across various Australian rail networks.

Operating on a 1435 mm gauge and utilizing 1.5 kV DC electric systems, the NSW 86 has served with distinction in various Australian rail operators, including FreightCorp, Freightrail, and the NSW Rail Transport Museum.

Explore the history and capabilities of this iconic Australian electric locomotive.

Comeng NSW 86 technical specifications

	Value	Imperial / US
Built by	Comeng · 1982–198550 units
Top speed	130 km/h81 mph	81 mph
Power output	2,700 kW3,621 hp	3,621 hp
Tractive effort	222 kN49,908 lbf	49,908 lbf
Electric systems	1.5 kV DC
Track gauge	1,435 mmStandard gauge4 ft 8½ in	4 ft 8½ in
UIC axle arrangement	Co'Co'
Width	2.95 m9 ft 8 in	9 ft 8 in
Height	4.4 m14 ft 5 in	14 ft 5 in
Weight	119 t262,350 lb	262,350 lb

Source of the data: en.wikipedia.orgView this model on trainspo.com Spotted an error? Let us know

Operators of the Comeng NSW 86

Railway companies that have operated the NSW 86, with the class designation used by each of them.

Operator	Class	Country
Dorrigo Steam Railway and Museum	DSRM 86	Australia
FreightCorp	FreightCorp 86	Australia
Freightrail	Freightrail 86	Australia
NSW Rail Transport Museum	NSWRTM 86	Australia
Southern and Silverton Rail	Silverton 86	Australia
