CRRC Ziyang SS4G

Built by Dalian, Datong, Zhuzhou, Ziyang

Top speed

100 km/h

62 mph

Power output

6,400 kW

8,583 hp

Weight

184 t

405,650 lb

Length

15.2 m

49 ft 10 in

Track gauge

1,435 mm

Standard gauge

Years built

1993–2007

1,347 units

Overview of the CRRC Ziyang SS4G

Discover the powerful SS4G electric locomotive, a railway giant designed for heavy-duty freight transport.

Boasting an impressive power output of 6400 kW and a tractive effort of 628 kN, the SS4G is engineered to move substantial loads efficiently. Its Bo'Bo'+Bo'Bo' wheel arrangement and a weight of 184 tons provide exceptional stability on the tracks.

Manufactured in China by China Railway Corporation, this versatile locomotive has been a cornerstone of the Chinese railway network since its introduction. Its standard gauge of 1435 mm and compatibility with 25 kV AC 50 Hz electrical systems ensure broad operational capabilities.

The SS4G features robust dimensions, measuring 15.2 meters in length, 3.1 meters in width, and 4.04 meters in height, with an axle load of 23 tons. It can reach a top speed of 100 km/h, facilitating competitive transit times for cargo.

CRRC Ziyang SS4G technical specifications

	Value	Imperial / US
Series	SS4
Built by	Dalian, Datong, Zhuzhou, Ziyang · 1993–20071,347 units
Top speed	100 km/h62 mph	62 mph
Power output	6,400 kW8,583 hp	8,583 hp
Tractive effort	628 kN141,180 lbf	141,180 lbf
Electric systems	25 kV AC 50 Hz
Track gauge	1,435 mmStandard gauge4 ft 8½ in	4 ft 8½ in
UIC axle arrangement	Bo'Bo'+Bo'Bo'
Length	15.2 m49 ft 10 in	49 ft 10 in
Train length	30.4 m99 ft 9 in	99 ft 9 in
Width	3.1 m10 ft 2 in	10 ft 2 in
Height	4.04 m13 ft 3 in	13 ft 3 in
Weight	184 t405,650 lb	405,650 lb
Axle load	23 t50,706 lb	50,706 lb
