Fiat E491

Built by Fiat, Ansaldo

Top speed

140 km/h

87 mph

Power output

3,400 kW

4,559 hp

Weight

86 t

189,597 lb

Length

17 m

55 ft 9 in

Track gauge

1,435 mm

Standard gauge

Years built

1986–1990

19 units

Overview of the Fiat E491

Discover the E491 electric locomotive, a powerful Italian-built machine crafted by Fiat and Ansaldo between 1986 and 1990.

This impressive locomotive boasts a top speed of 140 km/h, making it a vital asset for Italian railways. Its robust construction, measuring 17 meters long and weighing 86 tons, ensures reliability and strength on the tracks.

Operating on 25 kV AC 50 Hz and delivering a substantial 3400 kW of power, the E491 is engineered for diverse railway operations. It stands as a significant contributor to the Italian State Railways fleet.

Fiat E491 technical specifications

	Value	Imperial / US
Series	E491
Built by	Fiat, Ansaldo · 1986–199019 units
Top speed	140 km/h87 mph	87 mph
Power output	3,400 kW4,559 hp	4,559 hp
Electric systems	25 kV AC 50 Hz
Track gauge	1,435 mmStandard gauge4 ft 8½ in	4 ft 8½ in
UIC axle arrangement	Bo'Bo'
Length	17 m55 ft 9 in	55 ft 9 in
Width	3 m9 ft 10 in	9 ft 10 in
Height	4.31 m14 ft 2 in	14 ft 2 in
Weight	86 t189,597 lb	189,597 lb
