CRRC Dalian CKD8E

Built by CNR Dalian

Top speed

120 km/h

75 mph

Power output

2,580 kW

3,460 hp

Weight

120 t

264,554 lb

Length

20.67 m

67 ft 10 in

Track gauge

1,000 mm

Metre gauge

Years built

2005

20 units

Overview of the CRRC Dalian CKD8E

Explore the powerful CKD8E diesel locomotive, a robust and reliable workhorse in railway transportation.

Built by CNR Dalian in 2005, this locomotive boasts impressive capabilities, including a top speed of 120 km/h and a significant power output of 2580 kW, making it ideal for demanding operations.

With its Co'Co' wheel arrangement and a width of 2.8 meters, the CKD8E is designed to navigate various railway infrastructures efficiently.

Currently serving Keretapi Tanah Melayu Berhad (KTMB) in Malaysia, this diesel locomotive exemplifies efficiency and dependability in rail freight.

Measuring 20.67 meters in length and weighing 120 tons, its substantial dimensions reflect its robust construction and operational strength.

Equipped with a MAN 16RK215T prime mover, it delivers a formidable tractive effort of 410 kN, crucial for hauling heavy loads.

This 1000 mm gauge locomotive plays a vital role in the Malaysian rail network, showcasing advanced engineering and performance.

CRRC Dalian CKD8E technical specifications

	Value	Imperial / US
Built by	CNR Dalian · 200520 units
Top speed	120 km/h75 mph	75 mph
Power output	2,580 kW3,460 hp	3,460 hp
Tractive effort	410 kN92,172 lbf	92,172 lbf
Prime mover	MAN 16RK215T
Track gauge	1,000 mmMetre gauge3 ft 3⅜ in	3 ft 3⅜ in
UIC axle arrangement	Co'Co'
Length	20.67 m67 ft 10 in	67 ft 10 in
Width	2.8 m9 ft 2 in	9 ft 2 in
Height	3.88 m12 ft 9 in	12 ft 9 in
Weight	120 t264,554 lb	264,554 lb
