CRRC Dalian CKD8G Diesel Locomotive: Specs & Photos

Overview of the CRRC Dalian CKD8G

Experience the robust power of the CKD8G diesel locomotive, a testament to modern engineering built by CNR Dalian in 2013.

This impressive machine boasts a top speed of 120 km/h and a formidable 2200 kW power output, making it ideal for demanding freight and passenger operations.

Its Co'Co' axle configuration and substantial 120-ton weight provide exceptional traction and stability across various track conditions.

Powered by a reliable MTU 16V 4000 R43 prime mover, the CKD8G ensures efficient and long-lasting performance.

With generous dimensions of 19.86 meters in length, 3.1 meters in width, and 4.21 meters in height, it is well-suited for diverse railway infrastructures.

The 1676 mm gauge allows it to seamlessly integrate with operations like those of Trenes Argentinos Operadora Ferroviaria in Argentina, where it is classified as the SOFSE CKD8G.

Discover the technical prowess that positions the CKD8G as a leading choice in the world of diesel locomotives.

CRRC Dalian CKD8G technical specifications

	Value	Imperial / US
Series	CNR CKD8
Built by	CNR Dalian · 2013
Top speed	120 km/h75 mph	75 mph
Power output	2,200 kW2,950 hp	2,950 hp
Prime mover	MTU 16V 4000 R43
Track gauge	1,676 mmIndian broad gauge5 ft 6 in	5 ft 6 in
UIC axle arrangement	Co'Co'
Length	19.86 m65 ft 2 in	65 ft 2 in
Width	3.1 m10 ft 2 in	10 ft 2 in
Height	4.21 m13 ft 10 in	13 ft 10 in
Weight	120 t264,554 lb	264,554 lb
