CRRC Dalian DF4DH

Built by CNR Dalian

Top speed

100 km/h

62 mph

Power output

2,940 kW

3,943 hp

Weight

138 t

304,238 lb

Length

21.1 m

69 ft 3 in

Track gauge

1,435 mm

Standard gauge

Years built

2012

Overview of the CRRC Dalian DF4DH

Discover the powerful DF4DH diesel locomotive, a true workhorse of the railway.

Built by CNR Dalian in 2012, this locomotive is a key asset for the China Railway Corporation. With a top speed of 100 km/h and an impressive weight of 138 tons, it is designed to handle the demands of modern transportation.

Its technical specifications include a Co'Co' axle configuration, a length of 21.1 meters, and a height of 4.75 meters. The heart of this machine is its CRRC Dalian 16V240ZJD2 engine, which delivers a power output of 2940 kW.

The DF4DH locomotive, with its robustness and efficiency, exemplifies Chinese railway engineering, optimized for service on 1435 mm gauge tracks.

CRRC Dalian DF4DH technical specifications

	Value	Imperial / US
Series	DF4
Built by	CNR Dalian · 2012
Top speed	100 km/h62 mph	62 mph
Power output	2,940 kW3,943 hp	3,943 hp
Prime mover	CRRC Dalian 16V240ZJD2
Track gauge	1,435 mmStandard gauge4 ft 8½ in	4 ft 8½ in
UIC axle arrangement	Co'Co'
Length	21.1 m69 ft 3 in	69 ft 3 in
Width	3.31 m10 ft 10 in	10 ft 10 in
Height	4.75 m15 ft 7 in	15 ft 7 in
Weight	138 t304,238 lb	304,238 lb
